PNEUMATIC CONVEYING POWER INDUSTRY APLICATION



Bulk material handling in coal fired power plants, cement plant and all associated sectors of industry is big business.  The good engineered product range includes everything from pneumatic conveying for bulk material handling at all process stages in the power plant industry. We can convey everything from coal, limestone, biomass and other alternative fuels to by-products from power plants such as ash and gypsum. TeknoConvey components are a guarantee of maximum reliability and precision; for every boiler type and a very wide range of material properties.



To describe dense phase conveying in a few words: pneumatic conveying is the simplest way to transport dry bulk materials by using a low cost efficient equipment. The system of a pneumatic conveying system is simple   consists of a pressure vessel that pumps the materials (powders, granules or other dry bulk materials) via  closed horizontal or vertical pipelines by using compressed air to use low velocity, meaning a less wear of the pipelines and your pruducts.



Dense phase conveying systems use compressed air at above 1 Barg (0.5 - 0.8 possible dependent on powder and convey line) to push materials from a pressure vessel, transfer unit or pressure pot or vessel through a pipeline to a destination where the air and product are separated by simple small fitler not as lean phase pneumatic conveying system need’s.

Some materials that are not suitable for pneumatic conveying with large particle size, with high bulk density, and the extremely sticky materials, since they tend to build a coating on material contact surfaces and can eventually block the conveying line. It is very important that particles are fine enough and without big lumps the materials must be 90% smaller than 1mm for effective pneumatic conveying , and theconveying materials moisture must be lower than 5-4%.



We has big  experience in conveying just about every product,  all our customer can rest assured that their bulk material conveying system will provide ideal performance in their request.



Pneumatic  Dense Phase for grount handled, bulk bag unloading,  weighed, batched, mixed  bulk materials.

Flexible and simple and installation can route allmost everywhere in conveying lines

Free dust process

Max low degradation less than 5-6%

Low maintenance just a few moving parts

Can include automated process

Fast and low cost installation

Completly  guaranteed

Quiet operation

Can be designed to any rate

Safer environment

Cleaner handling space

Reduced manpower
